Fully Automatic Carton Sealing Machine

Fully Automatic Carton Sealing Machine Model No. SP CS5050A Fully-automatic model for ranom size cartons and integrated Packing Line FEATURES Automatically accepts cartons from a powered conveyor and closes all 4 carton flaps Automtically seals carton top and bottom with adhesive tape Automatically meter cartons with a photo eyed controlled gating system Fully-automatic operation and no operator required Ideal to be integrated into production conveyor to form a fully-automatic packing line Major and minor flaps folding, four flaps folder device Fully adjustable plow system allows plows to be adjusted vertically and horizontally at the front and the back of the plow Top squeezing rollers helps to keep the major flaps together while generally keeping the carton square prior to tape application. Adjustable hand cranks located on machine’s either sizes allow for quick carton change over Simple designed and maintenance free Tape Head to to accept 2” or 3” adhesive tape Carton indexing and gating device automatically puts 16" between cartons No Length set up, only height and width 2 easy load 2" or 3” interchangeable Tape Heads for top & bottom seal Top Tape Head can be repositioned for off centre seal Adjustable height legs with casters TECHNICAL DATA Tape Width 2” or 3” Optional Carton Size W 120-500 MM, H 160-500 MM Belt Speed Max. 13 M/ Min Air Consumption 6 KGs/ CM2 Overall Size L1980 x W950 x H1625 MM Power Supply 380 V, 50 Hz, 3 Phases
